Augercast Piles

Augercast piles, slender foundation support members, transmit loads to the ground through skin friction between the pile surface and surrounding soil. These piles are traditionally used as a foundation element but are also a wise choice when a vertical element is required in ground with the potential to cave. Drill Tech installs augercast piles with low-strength, lean-mix backfill concrete. This method minimizes chipping common to high-strength concrete and is especially beneficial for projects that plan to install lagging or remove support beams.

Construction Process

Augercast piles are drilled into the ground with a hollow-stem, continuous-flight auger to a specified depth. The piles range from 16 to 36 inches in diameter and are pumped with high-strength cement grout under pressure as the auger is withdrawn. If required, our team installs steel reinforcement while the cement is still fluid; depending on the project, piles are reinforced with either a rebar cage or a high-strength bar.

Benefits of Use

Augercast piles are especially effective in projects where the ground may cave under traditional CIDH drilling conditions. Our team also recommends them for work sites with noise or environmental sensitivities, as augercast piles cause minimal disturbance compared to driven piles. Drill Tech engineers have decades of experience designing concrete mixes appropriate for applicable projects and are familiar with the sequence planning required for an efficient on-site build.

Applicable Projects

Temporary Soldier Pile Shoring

Volume-Sensitive Sites

Environmentally Sensitive Sites

Construction Process

Augercast piles are drilled into the ground with a hollow-stem, continuous-flight auger to a specified depth. The piles range from 16 to 36 inches in diameter and are pumped with high-strength cement grout under pressure as the auger is withdrawn. If required, our team installs steel reinforcement while the cement is still fluid; depending on the project, piles are reinforced with either a rebar cage or a high-strength bar.

Benefits of Use

Augercast piles are especially effective in projects where the ground may cave under traditional CIDH drilling conditions. Our team also recommends them for work sites with noise or environmental sensitivities, as augercast piles cause minimal disturbance compared to driven piles. Drill Tech engineers have decades of experience designing concrete mixes appropriate for applicable projects and are familiar with the sequence planning required for an efficient on-site build.

Applicable Projects

Temporary Soldier Pile Shoring

Volume-Sensitive Sites

Environmentally Sensitive Sites

Construction Process

Augercast piles are drilled into the ground with a hollow-stem, continuous-flight auger to a specified depth. The piles range from 16 to 36 inches in diameter and are pumped with high-strength cement grout under pressure as the auger is withdrawn. If required, our team installs steel reinforcement while the cement is still fluid; depending on the project, piles are reinforced with either a rebar cage or a high-strength bar.

Benefits of Use

Augercast piles are especially effective in projects where the ground may cave under traditional CIDH drilling conditions. Our team also recommends them for work sites with noise or environmental sensitivities, as augercast piles cause minimal disturbance compared to driven piles. Drill Tech engineers have decades of experience designing concrete mixes appropriate for applicable projects and are familiar with the sequence planning required for an efficient on-site build.

Applicable Projects

Temporary Soldier Pile Shoring

Volume-Sensitive Sites

Environmentally Sensitive Sites
